Overview
GAOTek cantilever electronic line tester is precision casting body, strong structure, reliable and durable. precision workpiece positioning device, test point accurate positioning. pre treatment automatic milling, milling depth can be adjusted. online whole process multiple sensors, automatic testing of the workpiece, no need to be on duty. the HD image processing module can take a closed snapshot of the indentation and automatically display the hardness value. test data remote transmission, transmission tens of meters, transmission tens of meters. upgrade 4 G network wireless transmission and expand the internet of things system.
Technical Specifications
| Maximum Moving Distance Of Table | 7.8 in (200 mm) |
| Power Supply | AC 220 V, 50 Hz |
| Application | Metal, Plastic |
| Calibrating Method | Standard Hardness Test Blocks |
| The Maximum Allowable Height Of The Spec | 23.6 in (600 mm) |
| Distance Between The Two Columns | 25.1 in (640 mm) |
| Size | 48.8 in x 39.3 in x 78.7 in (1240 mm x 1000 mm x 2000 mm) |
| Weight | 2000 lb (1 t) |
